Hypalon is a type of synthetic rubber sheeting known for its exceptional resistance to
chemicals, weathering, and UV resistance. It has an excellent mechanical and good abrasion
properties even without reinforcing filters and has a reasonable resilience in grades over
60° shore A.
It displays good resistance to heat, ozone, oil and weathering and also gives good adhesion
to metal. The recommended operating temperature range is between -40°C to +125°C.
Hypalon CSM rubber sheet is widely used as gaskets, seals, lining in Chemicals and oil
resistance application, marine application, Fire retardant application etc.
| CSM (HYPALON) Rubber Sheet | |||||||
|---|---|---|---|---|---|---|---|
| Code | Colour | Specific Gravity | Hardness (±5) | Tensile Strength | Elongation | Polymer Content | Finish Type |
| Gm/cm3 | Shore A | kg / cm2 | % (min) | ||||
| HN60130 | Black/White | 1.3 | 60 | 100 | 350 | 100% | Smooth/Fabric |
| HN70140 | Black/White | 1.4 | 70 | 70 | 350 | 100% | Smooth/Fabric |
| HN65140 | Black/White | 1.4 | 65 | 100 | 350 | 100% | Smooth/Fabric |
| Standard Length | 10 Mtr | 33 Ft | 11 Yard |
| Standard Width | 1.2/1.4/1.5/2 Mtr | 4/4.6/4.92/6.56 Ft | 1.33/1.53/1.64/2.18 Yard |
1. One side or both side smooth or fabric finish can be supplied.
2. Specifications are subject to change without notice.
3. Custom Color Available.
